| Diameter: | 5 - 60 m |
| Design Pressure: | 1.0 - 1.6 MPa |
| Length: | > 1.5m |
| Application Industries: | Building Material, AAC plant |
| Autoclave Opening Method: | Electric-opening, Hydraulic-opening, Pneumatic-opening, Side-opening, Top-opening |
| Manufacturing Standards: | With GB & TSG, ISO, EAC, ASME and CE standard, for export to Asia, Africa, Americas, CIS, etc. |
| Technological Advantages: | High-quality raw materials, advanced processing technology, flexible structure and reliable. |
| Model | kettle diameter (m) |
Effective length | Maximum working pressure (Mpa) |
Maximum working temperature(℃) |
Design pressure (Mpa) |
Design temperature(℃) |
Working mediu | Total length L(m) |
Width W(m) |
Height H(m) |
| FGZCS 1.0-1.65 x L | Φ1.65 | Customized | 1.0 | 183 | 1.1 | 187 |
Saturated |
L+0.65 | 2.619 | 2.595 |
| FGZCS 1.3-1.65 x L | Φ1.65 | 1.3 | 195 | 1.4 | 198 | L+0.65 | 2.619 | 2.595 | ||
| FGZCS 1.0-2.0 x L | Φ2.0 | 1.0 | 183 | 1.1 | 187 | L+0.9 | 2.965 | 3.225 | ||
| FGZCS 1.1-2.0 x L | Φ2.0 | 1.1 | 187 | 1.2 | 192 | L+0.9 | 2.965 | 3.225 | ||
| FGZCS 1.3-2.0 x L | Φ2.0 | 1.3 | 195 | 1.4 | 198 | L+0.9 | 2.965 | 3.225 | ||
| FGZCS 1.5-2.0 x L | Φ2.0 | 1.5 | 201 | 1.6 | 204 | L+0.9 | 2.965 | 3.255 | ||
| FGZCS 1.3-2.2 x L | Φ2.2 | 1.3 | 194 | 1.4 | 197 | L+1.3 | 3.288 | 3.43 | ||
| FGZCS 1.5-2.2 x L | Φ2.2 | 1.5 | 201 | 1.6 | 204 | L+1.3 | 3.288 | 3.43 | ||
| FGZCS 1.3-2.4 x L | Φ2.4 | 1.3 | 194 | 1.4 | 197 | L+1.56 | 3.154 | 3.917 | ||
| FGZCS 1.5-2.4 x L | Φ2.4 | 1.5 | 201 | 1.6 | 204 | L+1.56 | 3.154 | 3.917 | ||
| FGZCS 1.3-2.5 x L | Φ2.5 | 1.3 | 195 | 1.4 | 197 | L+1.56 | 3.254 | 4.017 | ||
| FGZCS 1.5-2.5 x L | Φ2.5 | 1.5 | 201 | 1.6 | 204 | L+1.56 | 3.254 | 4.017 | ||
| FGZCS 1.3-2.68 x L | Φ2.68 | 1.3 | 194 | 1.4 | 197 | L+1.754 | 3.28 | 4.143 | ||
| FGZCS 1.5-2.68 x L | Φ2.68 | 1.5 | 201 | 1.6 | 204 | L+1.754 | 3.28 | 4.143 | ||
| FGZCS 1.3-2.85 x L | Φ2.85 | 1.3 | 194 | 1.4 | 197 | L+1.754 | 3.58 | 4.493 | ||
| FGZCS 1.5-2.85 x L | Φ2.85 | 1.5 | 201 | 1.6 | 204 | L+1.754 | 3.58 | 4.493 | ||
| FGZCS 1.3-3.0 x L | Φ3.0 | 1.3 | 194 | 1.4 | 197 | L+1.8 | 4.537 | 4.66 | ||
| FGZCS 1.5-3.0 x L | Φ3.0 | 1.5 | 201 | 1.6 | 204 | L+1.8 | 4.537 | 4.66 | ||
| FGZCS 1.3-3.2 x L | Φ3.2 | 1.3 | 194 | 1.4 | 197 | L+1.9 | 4.74 | 5.131 | ||
| FGZCS 1.5-3.2 x L | Φ3.2 | 1.5 | 201 | 1.6 | 204 | L+1.9 | 4.74 | 5.131 |
Notes: * The above parameters are for reference only, subject to actual product specifications.
