Welcome to XHJ Boiler - China Leading Boiler Manufacturer
| Rated Steam: | 0.08 - 1.0 ton/h |
| Design Pressure: | ≤ 1.6 Mpa |
| Structure Type: | Vertical, Water Tube |
| Available Fuels: | Wood pellets, wood chips, palm kernel shell, rice husk, bagasse, coconut shell, crop straw. |
| Manufacturing Standards: | With GB & TSG, ISO, EAC, ASME and CE standard, for export to Asia, Africa, Americas, CIS, etc. |
| Application Industries: | Grain‑oil processing, food & beverage, textile, rubber, paper‑making, wood processing, feed, etc. |
| Technological Advantages: | Wide fuel adaptability for solid waste, coal and biomass, compact structure, easy operation, safe low‑pressure running, double‑deck grate secondary combustion for low fuel consumption. |
| Model | Rated evaporation(T/H) | Rated pressure (Mpa) | Saturation temperature(℃) | Thermal efficiency(%) | Water capacity(L) | Fuel consumption(Kg/H) | power supply(V) |
| LSG0.08-0.7 | 0.08 | 0.7 | 170 | ≥90 | 29.5 | 12 | 220 |
| LSG0.12-0.7 | 0.12 | 17 | |||||
| LSG0.16-0.7 | 0.16 | 25 | |||||
| LSG0.23-0.7 | 0.23 | 33 | |||||
| LSG0.30-0.7 | 0.3 | 50 | |||||
| LSG0.50-0.7 | 0.5 | 75 |
Notes: * The above parameters are for reference only, subject to actual product specifications.
R&D Center
Fully Automatic Welding
Fully Automatic Tube
Steel Plate Rolling
Tube Bending
CNC Cutting
Large Vertical Lathe
Quenching Treatment
X-ray Flaw Detection
SAPPI
GAZPROM
ADNOC
COCACOLA
CDPC
SINOPEC
CNPC
CHN ENERGY
BYD
CP FOOD
Factory Direct Supply
XHJ Boiler specializes in the R&D, production and sales of boilers, pressure vessels, heat exchange equipment and other related products. Supply customers with one-stop boiler and pressure vessel solutions and have won extensive recognition and positive reviews globally.
XHJ BOILER recommends China Vertical Wood Biomass Boiler Supplier to help you understand product manufacturing process, equipment features, and other details. Please visit www.xhjboiler.com and view related application cases, blog updates, and all products.
