Welcome to XHJ Boiler - China Leading Boiler Manufacturer
| Rated Steam: | 120 - 1000 kg/h |
| Design Pressure: | 0.6 - 1.0 Mpa |
| Thermal Efficiency: | 85% |
| Rated Steam Temperature: | 175 ℃ |
| Available Fuels: | Biomass wood pellets, straw pellets, rice husk pellets, wood chips, agricultural waste, etc. |
| Application Industries: | Widely applied in food, textile, pharmaceutical, chemical and laundry industries for industrial steam production. |
| Technological Advantages: | Cost‑effective biomass steam generator with 85% efficiency, compact movable design and full‑automatic intelligent control. |
| Model | Rated steam capacity (Kg/h) | Rated working pressure (Mpa) | Induced fan power (W) | Fd fan power (W) | Feeding motor power (W) | Pump power (W) | Power consumption (KW/h) | Thermal efficiency (%) | Fuel consumption (Kg/h) | Safety valve (Mpa) | Overall dimensions (mm) | Dust collector (mm) | Shipping weight (kg) |
| LSS‑0.12‑0.6 | 120 | 0.6 | 250 | 85 | 250 | 750 | 1.34 | 85 | 17 | 0.58 | 1700×650×1550 | Φ520×1350 | 728 |
| LSS‑0.15‑0.6 | 150 | 0.6 | 370 | 120 | 250 | 750 | 1.49 | 85 | 22 | 0.58 | 1700×700×1650 | Φ550×1455 | 880 |
| LSS‑0.2‑0.7 | 200 | 0.6 | 550 | 120 | 250 | 750 | 1.67 | 85 | 29 | 0.58 | 1850×750×1700 | Φ550×1455 | 980 |
| LSS‑0.3‑0.7 | 300 | 0.7 | 550 | 330 | 250 | 1100 | 2.23 | 85 | 43 | 0.68 | 2000×1320×1800 | Built in dedusting | 1480 |
| LSS‑0.5‑0.7 | 500 | 0.7 | 750 | 500 | 250 | 1500 | 3 | 85 | 58 | 0.68 | 2470×1480×1940 | Built in dedusting | 2000 |
| LSS‑0.75‑0.7 | 750 | 0.7 | 2200 | 500 | 250 | 2200 | 5.15 | 85 | 108 | 0.68 | 1860×1350×2200 | Φ755×2000 | 2500 |
| LSS‑1.0‑0.7 | 1000 | 0.7 | 4000 | 500×2 | 250 | 2200 | 7.45 | 85 | 158 | 0.68 | 2100×1650×2750 | Φ755×2000 | 2900 |
Notes: * The above parameters are for reference only, subject to actual product specifications.
R&D Center
Fully Automatic Welding
Fully Automatic Tube
Steel Plate Rolling
Tube Bending
CNC Cutting
Large Vertical Lathe
Quenching Treatment
X-ray Flaw Detection
SAPPI
GAZPROM
ADNOC
COCACOLA
CDPC
SINOPEC
CNPC
CHN ENERGY
BYD
CP FOOD
Factory Direct Supply
XHJ Boiler specializes in the R&D, production and sales of boilers, pressure vessels, heat exchange equipment and other related products. Supply customers with one-stop boiler and pressure vessel solutions and have won extensive recognition and positive reviews globally.
XHJ BOILER recommends China Biomass Fired Steam Generator Manufacturer to help you understand product manufacturing process, equipment features, and other details. Please visit www.xhjboiler.com and view related application cases, blog updates, and all products.
