Welcome to XHJ Boiler - China Leading Boiler Manufacturer
| Rated Steam: | 0.5 - 1 ton/h |
| Design Pressure: | 1 MPa |
| Thermal efficiency: | 98% |
| Effective Water Volume: | ＜ 30 m³ |
| Rated Steam Temperature: | 184 ℃ |
| Available Fuels: | Natural Gas, LNG, LPG, Biogas, Oil, Diesel, etc. |
| Application Industries: | Widely applied in food, textile, pharmaceutical, chemical and laundry industries for industrial steam production. |
| Item/Model | Rated capacity (t/h) | Rated steam pressure (MPa) | Rated steam temperature (℃) | Effective water volume (m³) | Thermal efficiency (Natural gas) (%) | Exhaust gas temperature design (℃) | Natural gas consumption (Nm³/h) | Steam production time (min) | Water inlet (mm) | Steam outlet (mm) | Safety valve port (mm) | Discharge outlet (mm) | Chimney φ (mm) |
| SLSS0.5‑1.0‑Q | 500 | 1 | 184 | <30 | >98 | 90 | 37.4 | 3 | DN25 | DN40 | DN40 | DN25 | 273 |
| SLSS1‑1.0‑Q | 1000 | 1 | 184 | <30 | >98 | 90 | 74.8 | 3 | DN25 | DN40 | DN40 | DN25 | 273 |
Notes: * The above parameters are for reference only, subject to actual product specifications.
R&D Center
Fully Automatic Welding
Fully Automatic Tube
Steel Plate Rolling
Tube Bending
CNC Cutting
Large Vertical Lathe
Quenching Treatment
X-ray Flaw Detection
SAPPI
GAZPROM
ADNOC
COCACOLA
CDPC
SINOPEC
CNPC
CHN ENERGY
BYD
CP FOOD
Factory Direct Supply
XHJ Boiler specializes in the R&D, production and sales of boilers, pressure vessels, heat exchange equipment and other related products. Supply customers with one-stop boiler and pressure vessel solutions and have won extensive recognition and positive reviews globally.
XHJ BOILER recommends China Gas&Oil Fired Steam Generator Manufacturer to help you understand product manufacturing process, equipment features, and other details. Please visit www.xhjboiler.com and view related application cases, blog updates, and all products.
