Welcome to XHJ Boiler - China Leading Boiler Manufacturer
| Electric Power: | 6 - 240 KW |
| Boiling Water Output: | 60 - 2000 L/h |
| Bath Water Output: | 150 - 5500 L/h |
| Water Volume: | 0.11 - 1.7 m³ |
| Thermal Efficiency: | 99% |
| Application Industries: | Hotels, schools, hospitals, office buildings, factories and public places for hot‑boiled water supply. |
| Technological Advantages: | Scale‑resistant water‑electric separation, easy maintenance, auto‑control, 100℃ boiling water, multi‑safety protection and premium heating components. |
| Item/Model | Electric power(kW) | Boiling water output(L/h) | Bath water output L/h Δt=25℃ | Water volume(m³) | Power supply(V/Hz) | Current(A) | Thermal efficiency(%) | Current outlet(mm) | Boiling water outlet(mm) | Sewage cleaning port(mm) | Atmospheric vent(mm) | Cleaning port(mm) | Overall dimensions of the boiler body‑L(mm) | Overall dimensions of the boiler body‑W(mm) | Overall dimensions of the boiler body‑H(mm) | Weight(T) |
| CKS60D‑Y | 6 | 60 | 150 | 0.11 | 380/50 | 9 | 99% | DN40 | DN15 | DN25 | DN32 | DN80 | 655 | 498 | 1160 | 0.11 |
| CKS120D‑Y | 12 | 120 | 300 | 0.11 | 380/50 | 18 | 99% | DN40 | DN15 | DN25 | DN32 | DN80 | 655 | 498 | 1160 | 0.11 |
| CKS240D‑Y | 24 | 240 | 600 | 0.11 | 380/50 | 36 | 99% | DN40 | DN15 | DN25 | DN40 | DN80 | 655 | 498 | 1175 | 0.11 |
| CKS360D‑Y | 36 | 360 | 900 | 0.18 | 380/50 | 54 | 99% | DN40 | DN15 | DN25 | DN40 | DN80 | 755 | 598 | 1275 | 0.17 |
| CKS500D‑Y | 54 | 500 | 1300 | 0.37 | 380/50 | 82 | 99% | DN40 | DN25 | DN25 | DN80 | DN80 | 1045 | 850 | 1632 | 0.28 |
| CKS1000D‑Y | 120 | 1000 | 2700 | 1.5 | 380/50 | 182 | 99% | DN40 | DN25 | DN40 | DN80 | DN80 | 1230 | 1475 | 2052 | 0.64 |
| CKS2000D‑Y | 240 | 2000 | 5500 | 1.7 | 380/50 | 362 | 99% | DN40 | DN25 | DN40 | DN80 | DN80 | 1370 | 1655 | 2177 | 1.07 |
Notes: * The above parameters are for reference only, subject to actual product specifications.
