| Boiling Water Output: | 240 - 6000 L/h |
| Water Volume: | 0.089 - 1.46 m³ |
| Design Pressure: | Atmospheric pressure (0 MPa) |
| Thermal efficiency: | 92 - 99% |
| Available Fuels: | Natural Gas, LNG, LPG, Oil, Diesel, Dual-fuel, etc. |
| Application Industries: | Ideal for schools, hospitals, hotels, office buildings, dormitories and public facilities. Also applicable for food, textile, breeding and general industrial hot water supply. |
| Technological Advantages: | Auto-run, Digital temperature display, Safe andreliable |
| Item/Model | CKS240 | CKS360 | CKS500 | CKS700 | CKS1000 | CKS1500 | CKS2000 | CKS3000 | CKS6000 |
| Boiling water output (L/h) | 240 | 360 | 500 | 700 | 1000 | 1500 | 2000 | 3000 | 6000 |
| Bath water output Δt=25℃ (L/h) | 600 | 900 | 1300 | 1800 | 2500 | 3750 | 5000 | 7500 | 15000 |
| Water volume (m³) | 0.089 | 0.15 | 0.25 | 0.25 | 0.5 | 0.5 | 0.75 | 1.35 | 1.46 |
| Diesel consumption (Kg/h) | 2 | 3.1 | 4.2 | 5.9 | 8.4 | 12.7 | 16.9 | 25.3 | 50.5 |
| Natural gas consumption (Nm³/h) | 2.38 | 3.6 | 5 | 7 | 10 | 15.1 | 20.1 | 30.1 | 60.2 |
| Gas consumption (Nm³/h) | 5.39 | 8.15 | 11.32 | 15.84 | 22.63 | 34.17 | 45.49 | 68.12 | 135.8 |
| Thermal efficiency (%) | 90% ~ 99% | ||||||||
| Power supply (V/Hz) | 220/50 | 380/50 | |||||||
| Boiling water outlet (mm) | DN25 | DN25 | DN25 | DN25 | DN40 | DN40 | DN40 | DN40 | DN80 |
| Water inlet (mm) | DN15 | DN15 | DN20 | DN20 | DN25 | DN25 | DN25 | DN25 | DN40 |
| Atmospheric vent (mm) | DN80 | DN80 | DN80 | DN80 | DN65 | DN65 | DN65 | DN80 | DN80 |
| Cleaning port (mm) | DN50 | DN50 | DN80 | DN80 | DN80 | DN80 | DN80 | DN80 | DN100 |
| Chimney φ (mm) | 108 | 108 | 159 | 159 | 159 | 159 | 219 | 219 | 325 |
| Overall dimensions L (mm) | 660 | 660 | 753 | 753 | 1000 | 1000 | 1120 | 1380 | 1470 |
| Overall dimensions W (mm) | 672 | 672 | 822 | 822 | 1072 | 1072 | 1244 | 1556 | 1466 |
| Overall dimensions H (mm) | 1138 | 1138 | 1488 | 1488 | 1840 | 1840 | 2116 | 2116 | 2586 |
| Weight (t) | 0.23 | 0.25 | 0.27 | 0.29 | 0.53 | 0.57 | 0.85 | 1.18 | 1.51 |
Notes: * The above parameters are for reference only, subject to actual product specifications.
