Welcome to XHJ Boiler - China Leading Boiler Manufacturer
| Rated Hot‑water: | 175 - 2800 kw |
| Water Outlet Temperature: | ≤ 95 ℃ |
| Effective Water Volume: | 22.5 - 460 m³ |
| Circulating Water: | 6 - 96 m³/h |
| Heating Area: | 2800 - 30000 m³ |
| Application Industries: | Widely used for heating & hot‑water in hotels, hospitals, schools, commercial buildings, food and pharmaceutical industries. |
| Technological Advantages: | Ultra-efficient, safe, smart and durable boiler with low installation cost and full service support. |
| Item/Model | ZLLN‑175 | ZLLN‑280 | ZLLN‑360 | ZLLN‑750 | ZLLN‑1100 | ZLLN‑1400 | ZLLN‑2100 | ZLLN‑2800 |
| Rated power (kW) | 175 | 280 | 360 | 750 | 1100 | 1400 | 2100 | 2800 |
| Rated supply and return water temperature (℃) | 85/60 | 85/60 | 85/60 | 85/60 | 85/60 | 85/60 | 85/60 | 85/60 |
| Heating area (㎡) | 2800 | 2920 | 3750 | 7500 | 11250 | 15000 | 22500 | 30000 |
| Effective water volume (m³) | 22.5 | 28 | 31.5 | 80 | 90 | 160 | 330 | 460 |
| Circulating water volume (m³/h) | 6 | 9.6 | 12.5 | 26 | 38 | 48 | 72 | 96 |
| Maximum outlet temperature (℃) | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 |
| Hot water output Δt=25℃ (m³/h) | 7.5 | 12 | 15.5 | 32 | 47 | 60 | 90 | 120 |
| Thermal efficiency (%) | 108 | 108 | 108 | 108.9 | 108.9 | 108.9 | 108.9 | 108.9 |
| Rated pressure (MPa) | Atmospheric | Atmospheric | Atmospheric | Atmospheric | Atmospheric | Atmospheric | Atmospheric | Atmospheric |
| Natural gas consumption (Nm³/h) | 16.2 | 25.2 | 32.4 | 64.8 | 97.2 | 129.6 | 194.4 | 259.2 |
| Supply and return water inlet (mm) | DN50 | DN50 | DN50 | DN100 | DN100 | DN125 | DN125 | DN150 |
| Chimney φ (mm) | 200 | 200 | 200 | 250 | 250 | 300 | 410 | 420 |
| Power supply (V/Hz) | 220/50 | 220/50 | 220/50 | 220/50 | 380/50 | 380/50 | 380/50 | 380/50 |
| Flue gas temperature (℃) | <65 | <65 | <65 | <65 | <65 | <65 | <65 | <65 |
| Noise dB(A) | ≤55 | ≤55 | ≤55 | ≤55 | ≤55 | ≤55 | ≤55 | ≤55 |
| Nitrogen oxides (NOₓ) (mg/Nm³) | <30 | <30 | <30 | <30 | <30 | <30 | <30 | <30 |
| Overall dimensions L (mm) | 1425 | 1425 | 1575 | 1840 | 2130 | 2275 | 2755 | 3900 |
| Overall dimensions W (mm) | 850 | 850 | 850 | 1015 | 1150 | 1050 | 1250 | 2200 |
| Overall dimensions H (mm) | 1300 | 1300 | 1450 | 1445 | 1630 | 1630 | 1900 | 1900 |
| Weight (kg) | 300 | 345 | 420 | 740 | 890 | 1460 | 1800 | 2500(2600) |
Notes: * The above parameters are for reference only, subject to actual product specifications.
