| Rated Hot‑water: | 0.35 - 2.8 MW |
| Effective Water Volume: | 59 - 430 m³ |
| Circulating Water: | 30 - 240 m³/h |
| Application Industries: | Widely applied in hotels, hospitals, schools, commercial buildings, food and pharmaceutical industries for heating and hot water demand. |
| Technological Advantages: | Designed direct-flow 316Ti stainless steel fins tubing, strong resistance to condensate corrosion and scaling extends lifespan by 2-3 times, the modular boiler design. |
| Item/Model | DWRS-350 | DWRS-700 | DWRS-1050 | DWRS-1400 | DWRS-2100 | DWRS-2800 |
| Rated power (kW) | 350 | 700 | 1050 | 1400 | 2100 | 2800 |
| Rated supply and return water temperature (℃) | 85/70 | 85/70 | 85/70 | 85/70 | 85/70 | 85/70 |
| Heating area (㎡) | 5000-7000 | 9000-14000 | 14000-20000 | 18000-28000 | 28000-40000 | 37000-56000 |
| Effective water volume (m³) | 59 | 85 | 195 | 215 | 390 | 430 |
| Circulating water volume (m³/h) | 30 | 60 | 90 | 120 | 180 | 240 |
| Thermal efficiency (%) | 103 | 103 | 103 | 103.5 | 103.5 | 103.5 |
| Rated pressure (MPa) | Atmospheric | Atmospheric | Atmospheric | Atmospheric | Atmospheric | Atmospheric |
| Natural gas consumption (Nm³/h) | 33.5 | 67 | 100.5 | 134 | 201 | 268 |
| Power supply (V/Hz) | 220/50 | 220/50 | 380/50 | 380/50 | 380/50 | 380/50 |
| Supply and return water inlet (mm) | DN65 | DN100 | DN125 | DN150 | DN125×2 | DN150×2 |
| Chimney φ (mm) | 200 | 250 | 250 | 300 | 250×2 | 300×2 |
| Flue gas temperature (℃) | <60 | <60 | <60 | <60 | <60 | <60 |
| Noise dB(A) | ≤40 | ≤40 | ≤40 | ≤40 | ≤40 | ≤40 |
| Nitrogen oxides (NOₓ) (mg/Nm³) | <30 | <30 | <30 | <30 | <30 | <30 |
| Overall dimensions L (mm) | 1810 | 2425 | 2500 | 2610 | 3000 | 3150 |
| Overall dimensions W (mm) | 985 | 1085 | 1235 | 1235 | 2235 | 2235 |
| Overall dimensions H (mm) | 1280 | 1460 | 1730 | 1780 | 1730 | 1780 |
| Weight (kg) | 700 | 1000 | 1200 | 1390 | 2300 | 2530 |
Notes: * The above parameters are for reference only, subject to actual product specifications.
